￭  型号 Model:CP-6.5

￭  声学性能Acoustic design:6.5"Passive loudspeaker,2-way

￭  配置Components:HF1×3"(纸盆高音) driver,LF1×6.5"(165mm)

￭  频率响应Frequent y range:60Hz-20KHz(±3dB)

￭  额定功率Power rating (RMS/Peak 10ms):100/180W

￭  标称阻抗Nominal impedance:8Ω

￭  覆盖角度Nominal dispersion angle: 90°×90°

￭  连接器Connections:1×NL4音箱座

￭  尺寸Dimensions (H×W×D):220mm×225mm×380mm

￭  型号 Model:CP-8

￭  声学性能Acoustic design:8"Passive loudspeaker,2-way

￭  配置Components:HF1×3"(纸盆高音） driver,LF1×8"(200mm)

￭  频率响应Frequent y range:60Hz-20KHz(±3dB)

￭  额定功率Power rating (RMS/Peak 10ms):150/250W

￭  标称阻抗Nominal impedance:8Ω

￭  覆盖角度Nominal dispersion angle: 90°×90°

￭  连接器Connections:1×NL4音箱座

￭  尺寸Dimensions (H×W×D):250mm×245mm×420mm

￭  型号 Model:CP-10

￭  声学性能Acoustic design:10"Passive loudspeaker,2-way

￭  配置Components:HF1×1"(25mm) driver,LF1×10"(250mm)

￭  频率响应Frequent y range:60Hz-20KHz(±3dB)

￭  额定功率Power rating (RMS/Peak 10ms):200W

￭  标称阻抗Nominal impedance:8Ω

￭  灵敏度Sensitivity(1w at 1m):97dB

￭  覆盖角度Nominal dispersion angle: 90°×70°

￭  连接器Connections:2×NL4音箱座

￭  尺寸Dimensions (H×W×D):320mm×320mm×490mm
