￭  型号 Model:KA-8

￭ 进口器件定制低音单元：1*8“+1*1.33”

￭  频率响应Frequent y range:70-20KHz(±3dB)

￭  额定功率Power rating (RMS/Peak 10ms):200W/400W(Max)

￭  灵敏度Sensitivity(1w at 1m):93dB

￭  最大声压级Maximum SPL1m:116db(RMS)

￭  标称阻抗Nominal impedance:8Ω

￭  覆盖角度Nominal dispersion angle: H90°×V70°

￭  连接器Connections:2×NL4音箱座

￭  尺寸Dimensions (H×W×D):265mm×295mm×444mm

￭  重量Weight:10.6Kg

￭  型号 Model:KA-10

￭  进口器件定制单元单元：1*10"+1*1.73“

￭  频率响应Frequent y range:60Hz-18KHz(±3dB)

￭  额定功率Power rating (RMS/Peak 10ms):300W/600W(Max)

￭  灵敏度Sensitivity(1w at 1m):96dB

￭  最大声压级Maximum SPL1m:121db(RMS)

￭  标称阻抗Nominal impedance:8Ω

￭  覆盖角度Nominal dispersion angle: 90°*70°

￭  连接器Connections:2×NL4音箱座

￭  尺寸Dimensions (H×W×D):310mm×334mm×518mm

￭  重量Weight：15Kg

￭  型号 Model:KA-12

￭  配置Components:1*12”+1*1.73“

￭  频率响应Frequent y range:55Hz-18KHz(±3dB)

￭  额定功率Power rating (RMS/Peak 10ms):400W/800W

￭  灵敏度Sensitivity(1w at 1m):98dB

￭  最大声压级Maximum SPL1m:124db(RMS)

￭  标称阻抗Nominal impedance:8Ω

￭  覆盖角度Nominal dispersion angle: 90°×70°

￭  连接器Connections:2×NL4音箱座

￭  尺寸Dimensions (H×W×D):360mm×400mm×599mm

￭  重量Weight:21Kg

￭  型号 Model:KA-15

￭  配置Components:1*15”+1*3”

￭  频率响应Frequent y range:50Hz-18KHz(±3dB)

￭  额定功率Power rating (RMS/Peak 10ms):600W/1200W

￭  灵敏度Sensitivity(1w at 1m):99dB

￭  最大声压级Maximum SPL1m:127db(RMS)

￭  标称阻抗Nominal impedance:8Ω

￭  覆盖角度Nominal dispersion angle: 90°×70°

￭  连接器Connections:2×NL4音箱座

￭  尺寸Dimensions (H×W×D):430mm×456mm×721mm

￭  重量Weight:28Kg
