￭  型号 Model:KP10

￭  声学性能Acoustic design:10"Passive loudspeaker,2-way

￭  配置Components:HF1×1.4"(44mm) driver,LF1×10"(65mm)

￭  频率响应Frequenty range:50Hz-20KHz(-10dB)

￭  额定功率Power rating (RMS/Peak 10ms):300W/1200W

￭  灵敏度Sensitivity(1w at 1m):95dB

￭  最大声压级Maximum SPL1m:122dB(Continuous);128dB(Peak)

￭  标称阻抗Nominal impedance:8Ω

￭  覆盖角度Nominal dispersion angle(HxV): 80°×50°

￭  连接器Connections:2×Speakon NL4

￭  尺寸Dimensions (H×W×D):524mm×300mm×340mm

￭  重量Weight:18.5Kg

￭  型号 Model:KP12

￭  声学性能 Acoustic design:12"Passive loudspeaker,2-way

￭  配置 Components:HF1×1.4"(44mm) driver, LF1×12"(75mm)

￭  频率响应 Frequenty range:50Hz-20KHz(-10dB)

￭  额定功率 Power rating (RMS/Peak 10ms):350W/1400W

￭  灵敏度 Sensitivity(1w at 1m):97dB

￭  最大声压级 Maximum SPL1m:124dB;130dB(Peak)

￭  标称阻抗 Nominal impedance:8Ω

￭  覆盖角度 Nominal dispersion angle(HxV): 80°×50°

￭  连接器 Connections:2×Speakon NL4

￭  尺寸 Dimensions (H×W×D):600mm×350mm×382mm

￭  重量 Weight:21Kg

￭  应用领域 Applications：KTV包房，夜总会，俱乐部，音乐餐吧，小型家庭娱乐。
