￭  型号 Model:PH10
￭  声学性能Acoustic design:10"Passive loudspeaker,2-way
￭  配置Components:HF1×1.4"(44mm)B&C driver,LF1×10"(65mm)
￭  频率响应Frequenty range:50Hz-20KHz(-10dB)
￭  额定功率Power rating (RMS/Peak 10ms):300W/1200W
￭  灵敏度Sensitivity(1w at 1m):97dB
￭  最大声压级Maximum SPL1m:121dB(Continuous);125dB(Peak)
￭  标称阻抗Nominal impedance:8Ω
￭  覆盖角度Nominal dispersion angle(HxV): 80°×50°
￭  连接器Connections:2×Speakon NL4
￭  尺寸Dimensions (H×W×D):540mm×310mm×340mm
￭  重量Weight:18.5Kg

￭  型号 Model:PH12

￭  声学性能 Acoustic design:12"Passive loudspeaker,2-way
￭  配置 Components:HF1×1.4"(44mm)B&C driver, LF1×12"(75mm)B&C
￭  频率响应 Frequenty range:50Hz-20KHz(-10dB)
￭  额定功率 Power rating (RMS/Peak 10ms):400W/1600W
￭  灵敏度 Sensitivity(1w at 1m):98dB
￭  最大声压级 Maximum SPL1m:123dB;126dB(Peak)
￭  标称阻抗 Nominal impedance:8Ω
￭  覆盖角度 Nominal dispersion angle(HxV): 80°×50°
￭  连接器 Connections:2×Speakon NL4
￭  尺寸 Dimensions (H×W×D):600mm×36.5mm×38.5mm

￭  重量 Weight:22Kg
￭  应用领域 Applications：KTV包房，夜总会，俱乐部，音乐餐吧，小型家庭娱乐。
